1) ESC changed into 60A from 50A.
Jan. 3rd, 2024 BeiJing Time
2) Flight Controller Gyro change from MPU6000 to ICM42688.
March 25th, 2024 BeiJing Time
Specifications: ( Diagram Picture)
Product Name | FLASH HOBBY F405 30.5x30.5 Flight Controller |
MCU | STM32F405 |
IMU(Gyro) | ICM42688 |
USB Port Type | Type-C |
Barometer | BMP280 |
OSD Chip | BetaFlight OSD w/ AT7456E chip |
DJI Air Unit Connection Way | Two ways supported: 6-pin connector or direct soldering. |
6-pin DJI Plug | Supported. Completely compatible with DJI O3/RunCam Link/Caddx Vista/DJI Air Unit V1, no wire is needed to be changed. |
Black box | 16M Black Box |
Current Sensor Input | Supported. For 50A ESC, please set scale = 180 and Ofset = 0. |
Power Input | 3S - 6S Lipo(Through ESC 8-PIN connector) |
5V BEC Output | 5 grous 5V outputuff0cthe total current load is 3A |
9V Output | 3 groups 9V outputuff0cthe total current load is 2.5A |
3.3V Output | 1 group 3.3V outputuff0cmaxmum current is 300mA |
ESC Signal | M1 - M4 |
UART | 6 sets(UART2 UART5, UART3), UART6(Dedicated for SBUS), UART4(Dedicated for ESC telemetry),UART1 (Dedicated for VTX data setting) |
Sbs | Debugging to UART6 Channel |
ESC Telemetry | UART R4(UART4) |
I2C | Supported. SDA & SCL pads on front side. Used for magnetometer. |
LED Pad | Supported. LED,5V, and GND pads on bottom of the front side. Used for WS2812 LED controlled by Betaflight firmware. |
Buzzer | supporteduff0c5V,BZ pads for 5V Buzzer |
BOOT Button | Supported. |
[A]. Press and hold BOOT button and power the FC on at the same time will force the FC to enter DFU mode, this is for firmware flashing when the FC gets bricked. | |
[B]. When the FC is powered on and in standby mode, | |
Supported Flight Controller Firmware | BetaFlight(Default), |
Firmware Target Name | STM32F405 |
